| CHASSIS |
ENGINE POWER |
| TATA / LEYLAND / EICHER / BHARAT BENZ 16 TON GVW |
500 KG X 2/ 1000 KG X 1 OR 500 KG X 1 WATER + FOAM + PUMP |
| TATA / LEYLAND / EICHER / BHARAT BENZ 25 TON GVW |
1000 KG + WATER + FOAM + PUMP OR |
| TATA / LEYLAND / EICHER / BHARAT BENZ 25 TON GVW |
2000 Kg x 2 DCP + REEL + MONITOR |
| GENERAL SPECIFICATION |
| Body |
Crew 1+5 – SCBA attachment / aluminum sandwich panels |
| Pump ( OPTIONAL ) |
UL - 3000 lpm @ 10bar, 4000 lpm @10 bar. & 300 lpm @ 40 bar - Optional. |
| Hose Reel |
ADCP REEL. 30 MTR X 2./ 4 60MTRX2 /4 |
| EQUIPMENTS |
1) Nitrogen Cylinder Storage Rack. With EXTRA BATTERY spare cylinders.
2) Control panel with LED Indication.
3) DCP Monitor.
4) Tank and pipeline Fabricated as per ASME Code - VIII
|
| Fitted Accessories |
Ext. ladder, light bar, P.A. system siren etc. |
