| CHASSIS |
ENGINE POWER |
| TATA LPT 1613 / 48 |
130 |
| Ashok Leyland 1616 il/1 |
160 |
| Eicher 20.16 / 48 |
147 |
| BHARAT BENZ-1617 any Equivalent |
170 |
| Chassis 25 Ton |
ENGINE POWER |
| TATA LPT 2518 |
180 |
| Ashok Leyland 2516 |
160 |
| Man 25.280.53. |
280 |
| BHARAT BENZ 2523 |
238 |
| GENERAL SPECIFICATION |
| Body |
M.S./ S.S. Structure aluminum body, aluminum rolling shutters aerodynamic (optional) |
| Water Tank |
4000 to 8000 Ltrs. M.S./S.S.304 |
| Foam Tank |
500 to 1000 ltr. SS 304/SS 316 |
| Pump |
2000 lpm @ 10kg or 3000 lpm @10 kg & 300@ 40 kg |
| Water Monitor |
Light weight aluminum, Range 60 to 75 mtr. manual/remote controlled |
| Hose Reel |
Auto rewind 60 mtr. with HP hose & jet / spray gun |
| Fitted Accessories |
Ext. ladder, light bar, siren, fire bell. |
| Optional |
Accessories as per IS-10460t |
Rescue Tools |
| Power Generator |
Light mast |
| Chain saw |
B.A. Set |
